Ceiling Laminar Air Flow Systems

Ceiling Laminar Air Flow Systems

80645 INR

Product Details:

X

Ceiling Laminar Air Flow Systems Price And Quantity

  • 80645 INR

Product Description

Specification



  •  ON/OFF Switch Socket 16 Amp ,230 V
  • Air flow Vertical  0.45+-0.05mps/90 fpm
  • Double Shaft Motor Blower  0.5/1.0 Hp , 2800 RPM , 1 Phase ,230 v
  • Electrical Supply 230V AC  1-Phase
  • Flourscent Light 500 LUX in Working Area
  • Hepa Filter  0.3 Micron
  • Box Type,Moc: Aluminium,Media:Micro Fiber Glass,
  • Efficiency:99.999% down to 0.3 Micron,Grade:H14  "
  • Magnehlic Guage 0-25 mm
  • "Noise/ Vibration Level Less than 67 dB on scale A when Ambient is not
  • greater than 55 dB on Scale A/Minimum"
  • "Pre filter 5 micron
  • Flange Type,Moc: Aluminium, Media:Non woven synthetic Polyester,Efficiency:95% down to 5 Micron,Grade:EU5"
  • PVC Curtain In All Four  Side
  • Roma Switch Socket modular Plate with on/off Switches for Motor & Light
  • SS 304 Ceiling Suspend Rod For LAF Hanging
  • SS 304 Sheet 1 mm Thik
  • SS Automosphere Nozzle (SS 304)
  • SS Dop Port for PAO Test
  • SS Filter Clamps(SS 304)
